Name: Powder Coated Meeting Room Sound Proof Partitions / Panels With Track System
Brand: EBUNGE

Product Description

Powder Coated Meeting Room Soundproof Sliding Partition With Track System

Specification of Bunge movable partition:

Bunge movable partition walls is made of high quality anodized aluminum frame with environmentally composite materials . The panels move on a ceiling track with no requirement of floor guides or rails ,

and they have a standard thickness of 65mm , 80mm and 100mm , and a width up to 1230mm . Maximum height can reach 13meter tall.

The accordion wall panel consists of a series of concave / convex profile interlocking flat panels and the fast set retractable top and bottom seals , it provides excellent acoustic insulation property of from STC – 32 to 53 in laboratory setting. Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant , schools , office , religion , hospitals , shopping arcades and many other indoor applications product.

Retractable room dividers wide of range face finishes are available : melamine faced MDF or Plywood , fabric , carpet , fabric , artificial , leather , wood veneer , high pressure laminate , Formica , acoustic panel , white boad ect. , panels may also be supplied unfinished for field decoration , Standard frame color is clear anodized aluminum , custom powder coating colors are available.

Bunge has adopted the advance partition technology of USA , Germany and Denmark . We have professional staff with more than 10 years of experience in design , production and installation.

Specifications of partitions:

Technical Parameter for Partition Panel	Panel Width	500 – 1230mm
	Panel height	2000 – 6000mm
	Sound proof	36 – 50 db
	Operation	Manual
	Frame	Aluminum
	Vertical profile	Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside
	Finish options	Fabric , veneer , HPL melamine , vinyl , carpet , customers own material, Bare finish
	Base options	Plywood , Gypsum , steel , MDF
	Max width	Unlimited
	Panel weight	25 – 40 kg / sq
Pass door selection	door	Single or double door
Seals	Top	Manual
Seals	bottom	Manual

Features :

1> Movable partition is modernized decoration style . It can separate the space speedly and

conveniently . And it has sound insulation and heat insulation and fireproof function .

2> The Partition Board is made from high density s / s frame , special made rubber , excellent sound insulation cotton and finish board etc. the finish board is flat and hard ;

3> The finish board is inserted in the aluminum track, assembled with multi direction wheels ; the board can be stored in may different ways ;

4> It doesn’t need track on the floor , we only hang the track on the ceilings and it can be at the same plane with the ceiling decoration . It won’t affect the whole decoration style ;

5> Around the board , there is sound insulation rubber , it can help to insulate the sound entering ;

6> The operation ways is much easier , it’s better than the old ways which was use spring before ;

We Offer:

â A full professional design service

â Survey and installation guide

â Using top quality materials and components

â A fully experienced work team

â Maintenance contracts to ensure your valuable asset remains in full work order.

FAQ:

1. How can you guarantee the quality ?

We have a modern management system . Take strict selection for upstream suppliers to insure the basic material to be good quality . And we pay more attention to production technology and staff training , so that the defective rate is less than 1% of each products, save cost at the production line . When the productions are ready, they would be sent to the package workshop , put in carton with foam between each panel to avoid the friction and damage.

2. Can you offer sample ?

Yes , we can offer standard samples for free , and customization is available.

3. Do you accept customization ?

Yes , we can support our clients with OEM , so that it can be easier to open the local market and build a long-term partnership between us .

4. How long is the lead time ?

Normally 10-25 days upon receiving the deposit, base on the quantity 1,500 SQM

5. Can you assist for installation ?

Yes, we can arrange to assist in installation if needed .

6. What are the factors of influencing the NRC?

Perforation rate , gap between the wall and panel , the density and thickness of the glass wool , etc. All these factors will effect NRC .

7. How to pay ?

You can pay by western union or T/T . Cash will be ok if we do business face to face .

Powder Coated Meeting Room Sound Proof Partitions / Panels With Track System 0

Specifications

Material	Aluminum Frame
Surface	Fabric , Melamine , Wall Paper, Wooden
Application	Hotel , Hall Meeting Room And So On
Type	Sliding Doors
Place Of Origin	China
Highlight	sounproof folding partition , movable soundproof partition
