Product Description
Decorative Modern Design Partition Movable Sound Proof Partitions for Banquet Hall
Specification:
Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space utilization.
Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centers, banks and restaurants.
Features:
1) Easy element adjustment after installation.
2) Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
3) Surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.
4) Consists of required full wall elements and telescopic elements with 2-point suspension system with steel-roller, extruded aluminium track.
EBUNGE Operable Wall Systems-Technical Information
| Item | Movable Partition Wall | |||
| Material | Melamine, Glass, Fabric,MDF | |||
| Type | Tempered Glass Partition Wall | |||
| Acoustic Folding Partition | ||||
| Surface Finish | 1. MDF Base board with Melamine Finish | |||
| 2. MDF board with Fabric Or Leather Finish | ||||
| 3. Plywood Or MDF base board without any finish | ||||
| Size and Design | Customized | |||
| Opening Style | Folding | |||
| Structure | Aluminum track, Trolley bearing, Acoustic Door Panel | |||
| Series | Thickness (mm) | Applied height (m) |
Sound Insulation(db) |
Referenced Weight |
| 65 | 65 | 2.0~4.5 | 32-36 | 30kg/m2 |
| 80 | 80 | 3.0~6.8 | 35-45 | 35kg/m2 |
| 100 | 100 | 5.0~8.0 | 43-53 | 45kg/m2 |
| 125 | 125 | 7.2~13.3 | 53-60 | 65kg/m2 |
| Package | ||||
| Carton package, MDF batten on four section sides , foam board on both front face. | ||||
| Installation | Easy Installation, Provide the installation instruction | |||
| Application | Meeting room, dining hall, exhibition hall, Function room,office etc. | |||
| Delivery Time | 35-45 days after receiving the deposit and confirming the shop drawing | |||
| Advantages | 1.Good performance of sound insulation, thermal insulation and Fire prevention | |||
| 2.Save much space for your building | ||||
| 3. No tracks on the floor, it’s easy to install and remove | ||||
| 4.Beautiful appearance, it is widely used in many spaces, such as meeting room,dining hall, exhibition hall, Function room and office | ||||
| 5. We can add single or double doors on the board for convenience | ||||
| 6. Supplied our products for many projects all over the world | ||||
Application:
Soundproof movable partitions can be used to Convention Centers, Gymnasiums, Religious Facilities, Hotel, Auditoriums, Corporate Training Facilities, Civic or Exposition Halls, Schools, Banquet Facilities etc. Soundproof movable partition systems, there are no more barriers to maximizing the potential of your available building spaces.
Specifications
| Panel Width | 500 Mm--1220 Mm (Accept Customized) |
|---|---|
| Material | MDF+Aluminum |
| Application | Hotel,office ,conference Room |
| Color | Color Selective (Customized) |
| Thickness | 65 Mm(2 9/16inch) |
| STC Conffcient | 32/50db |
| Feature | Voice Insulation |
| Finishing | Melanimine,fabric,leather Etc. |
| Highlight | sounproof folding partition , movable sound proof partitions |
Product Details
| Place of Origin | Guangdong |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO9001 |
| Model Number | Series 65 mm sound proof partitions |
| Packaging Details | Carton package, MDF batten on four section sides , foam board on both front face. |
