Product Description
Wooden Panel Material Operable Acoustic Folding Partition Walls For Office Partition Wall Project
1.Description
1- 65mm,85mm, 100mm aluminum frame thickness panel, Max height up to 15 meters.
2-Top supported without floor track or guide, only have a track on the ceiling.
3- clear anodized extruded aluminum tracks and frames, customized powder coated color are available.
4- Sound insulation certificate: STC 32db to 52db
5- Available in a wide range of finishes, melamine, fabric/PU leather, HPL, printing, etc.
6- Fast delivery and Rich experiences in oversea project installation guide & supervision.
2.Specifications of partitions:
| Technical Parameter for Partition Panel |
Panel Width | 500 – 1230mm |
| Panel height | 2000 – 6000mm | |
| Soundproof | 36 – 50 DB | |
| Operation | Manual | |
| Frame | Aluminum | |
| Vertical profile | Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside |
|
| Finish options | Fabric , veneer , HPL melamine , vinyl , carpet , customers own material, Bare finish |
|
| Base options | Plywood , Gypsum , steel , MDF | |
| Max width | Unlimited | |
| Panel weight | 25 – 40 kg / sq | |
| Pass door selection | door | Single or double door |
| Seals | Top | Manual |
| bottom | Manual |
3.FAQ:
1. What you should do on-site?
A beam(truss) should be built on-site for track installation. The min distance leaving for track installation from a false ceiling to top ceiling is 180mm.
2. How to install?
We will provide the installation manual and video guiding the installation job. We can also dispatch the installation engineer supervising the installation job onsite as request.
3. What is the lead time?
The lead time is 7 days to 10 days.For large quantity,about 500m²,15-20 days
4. How to transport?
Sea transportation is the usual way of transportation. In an emergency, can go by air
5. How do goods packing?
Paper packaging, MDF batten cover all-around the corner.
The movable wall panel and track, fittings will be packed separately.
7. What is the Procurement procedure?
1) send us the shop drawings(if the shop drawings is not available, you can tell us the height from false ceiling to finished floor and width from wall to wall)
Specifications
| General Use | Soundproof Partition Walls Are Used For Interior Decoration |
|---|---|
| Type | Office Furniture,folding Partition |
| Material | Aluminium,Stainless Steel |
| Color | Customized,Custom Color |
| Thickness | 65~125mm |
| Width | 750~~1200mm |
| Advantage | Professional Design Team&factory Manufacture&fashionable Outlook |
| Function | Office Partition Wall,soundproof |
| Surface Treatment | Melamine |
| Frame Material | Aluminium,6063-T6 Aluminum Alloy |
| Highlight | Operable Acoustic Folding Partition Walls , 125mm Folding Partition Walls |
Product Details
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO 9001 |
| Model Number | 65 mm sliding partition walls |
| Packaging Details | Paper carton, outside with wooden box. |
