Product Description
Factory Direct Sales Soundproof Movable Partition Wall Sliding Folding Partition For Ballroom
Product Description
The partition panel is made of aluminum frame, special made rubber, excellent sound insulation cotton, finish board, etc. The finish panel is flat and hard; The finish panel is inserted in the aluminum track, assembled with multi-direction wheels. The panel can be stored in many different ways. BUNGE movable partition wall is flexible and can be moved freely. And it has sound insulation, heat insulation and fireproof function.
Advantages
1. No rail suspension: the floor has no track, just install the track on the ceiling;
2. Stable and safe: stable and reliable after partitioning, not easy to swing;
3. Beautiful and generous: the surface is arbitrarily decorated, and can be combined with the interior decoration effect;
4. Retractable and flexible: the partition is freely retractable and flexible, and one person can complete the whole process of partitioning;
5. Convenient collection: When closing the board, the partition can be hidden in the special storage cabinet, which does not affect the overall appearance;
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm | ||
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point | ||
| Frame construction | Aluminum frame | ||
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Application:
Folding partition wall used in hotels, hotels, restaurants, conference halls, exhibition halls, high clean factories and offices.
About how to finalize order.
Please send your room drawing and provide requirements like partition surface finished and soundproof requirements, we will design the partition for free. After your confirmation, we can start production.
About the soundproof quality
From 30dB to 45 dB, depends of which type and what partition surface finished you need. Contact us and we will provide professional suggestions.
About finish options
There are wide of range face finishes are available: melamine faced MDF or plywood, fabric, carpet, fabric, PU leather, wood veneer, acoustic panel, ect., Panels can also be supplied unfinished for field decoration, Standard frame color is clear anodized aluminum, custom powder coating colors are available.
Specifications
| Product Name | Movable Partition Wall |
|---|---|
| Material | MDF |
| Color | Customized |
| Size | Customized |
| Thickness | 85 Mm |
| Application | Office,Restaurant,etc. |
| Height | Max 6 Meter |
| Width | 500-1220mm |
| Feature | Space Saving,Water-proof&air-proof&sound Isolation&heat Isolation |
| Advantage | Free Of Floor Track |
| Service | OEM/ODM |
| Highlight | movable partitions systems , acoustic movable walls |
Product Details
| Place of Origin | China (mainland) |
|---|---|
| Brand Name | EBUNGE |
| Model Number | 85 mm movable partition wall |
| Packaging Details | Carton package, MDF batten on four section sides, foam board on both front face. |
