Product Description
Type 80 retractable room divider soundproof partition wall aluminum frame movable partition walls for art gallery
Description:
The movable partition walls are a new way to divide spaces with elegance while respecting the architectural environment in which they are inserted.
They are composed of multiple individual elements, which flow along a horizontal guide attached to the ceiling, assembled one after another completing the entire wall.
It is not necessary any track on the floor, handling the elements is simple, fast and safe. The advantage of the folding partition wall is essential to occupy reduced space when it is parking, and when the wall is composed of all its elements.
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc. (Customized) | ||
Application:
Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room, ballroom, muti-function hall, restaurant, classroom, office, religion, dance studio, shopping arcades and many other places where seek for space divide with good soundproof performance.
Packing and shipping:
Packaging Details
Export carton box and wooden pallet or customized packaging.
Delivery Time
Shipped in 18 days after receiving the deposit payment, sliding partition wall quantity is less than 200 square meters.(T/T 40% deposit advanced, balanced before shipping).
Specifications
| Product Name | Movable Partition Walls |
|---|---|
| Material | Aluminium And Mdf Board |
| Height | Less Then 4 M |
| Width | 500-1200 Mm |
| Thickness | 65mm Aluminum Frame |
| Function | Sliding Room Divider |
| Finish | Melamine, Fabric, Leather, MDF Bare Finish |
| Highlight | movable walls on wheels , movable partitions systems |
Product Details
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | EBUNGE |
| Model Number | Series 65 mm acoustic room dividers |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
