Product Description
Conference Room Sound Proof Acoustic Movable Folding Wall Partitions
Specifications of BUNGE Acoustic Partitions System
| Model | BG65 Series | BG80 Series | BG100 Series | BG High-Series | |
| Suspensionsystem | Aluminum hanging | Steal Hanging | |||
| Basic Thickness | 65 mm | 80 mm | 100 mm | 100 mm | |
| Total thickness | 65/75/85/95mm | 80/90/100/110mm | 100/120/130mm | 100/120/130mm | |
| Max Height | Up to 3800 mm | Up to 6000 mm | Up to 8000 mm | Up to 15000 mm | |
| Width | 600-1230mm | 600-1230mm | 800-1230mm | 800-1230mm | |
| Floor/Ceiling Sealing Strength | Telescopic aluminum tube with rubber strip. | ||||
| Side walls sealing strength | Double seal tape | ||||
| Sound insulation level | 26-30 db | 28-34 db | 32-40 db | 42-52 db | |
| Panel structure | Aluminum frame with wooden keel | Aluminum frame with steel keel | |||
| Surface material | Melamine laminate/fabric/PU leather/wallpaper/veneer/customized | ||||
Section Configuration of BUNGE Acoustic Partitions System
1) Feld: acoustic fleece, pasted on the back of the panel, noise reducible and fire resistant(made in CHINA, GERMANY AND FRANCE)
2) Substrate(basal material): based on high quality of 12/15/18mm MDF with density of 750kg/m3,more choices for basal material:HDF, E1 ECO-friendly MDF and Fireproof MDF(B1 grade).
3) Surface: available in three different finishes: real wood veneer, printed wood melamine finished and fireproofing surface.
Features of BUNGE Acoustic Partitions System
1. Acoustic partitions can separate the space speedy and conveniently.
2. Top hung system without the need for a floor track.
3. Acoustic partition is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.
4. Around the acoustic partitions panel, there is sound insulation rubber, it can help to insulate the sound entering.
5.The acoustic partitions finished panel is hanging on the aluminum track, assembled with muti direction wheels.
Common Applications of Acoustic Partitions System
1. Studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.
2. Theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.
3. Meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.
4. Air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.
Our Services:
We ensure the Quick delivery and good quality guarantee.
Our company manufacture products according to buyer’s dimension quantity,
drawing or other related requirements.
After sales service including:
Overseas service availabe,
Using top quality materials and components.
Maintenance contracts to ensure your valuable asset remains in full work order.
Specifications
| Open Style | Sliding |
|---|---|
| Application | Hotel,banquet Hall |
| Panel Width | 500 Mm--1230 Mm |
| Product Name | Acoustic Partitions |
| Surface | Melamine |
| Feature | Sound Proofing |
| Highlight | acoustic operable wall , movable acoustic partition walls |
Product Details
| Place of Origin | Guangdong |
|---|---|
| Brand Name | BANGE |
| Certification | ISO9001 |
| Model Number | 85 mm acoustic partitions |
| Packaging Details | Carton package, MDF batten on four section sides , foam board on both front face. |
