Product Description
Silding partition walls folding door divider operable partition with melamine foldable partition for conference center
Description:
Movable walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost-effectiveness, they allow large rooms to be conveniently sub-divided to maximize space insulation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centuries, banks, and restaurants.
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc. (Customized) | ||
Feature:
Easy To move and soundproof
Thanks to the exclusive system: Polymer coated, self-lubricating, wear-resistant ball-bearing trolleys.
Technical reliability
In its versions, the range has undergone the most stringent endurance and mechanical resistance tests in laboratories or in its own Test Center. 3-years warranty for parts and labor.
Quick to install
Tool locking of top and bottom rubber seals thanks to a manual system in each panel.
Framework (stylist)
Aluminum profiles that become totally invisible when flat by means of a hollow joint system.
Advantage:
Long-term use: with more economy and higher decorative, beautiful and safe, will not scratch the skin.
Cost savings: installation does not affect the construction of smallpox and the ground.
Various forms: optional with a variety of occasions partition wall, can be customized according to customer requirements.
Easy combination: in the re-assembly can make full use of building materials.
Material environmental protection: the selection of high-quality melamine particleboard, sound insulation, and sealing a good variety of accessories a variety of options.
Specifications
| Product Name | Sliding Partition Walls |
|---|---|
| Material | Aluminium Frame And Mdf Board |
| Height | Less Then 6 M |
| Width | 500-1200 Mm |
| Thickness | 85mm |
| Function | Space Dividing,sound Proof |
| Style | Modern Style |
| Highlight | sliding folding partition , sound proof sliding partitions |
Product Details
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | EBUNGE |
| Model Number | Series 85 mm Sliding partition walls |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
