Sliding Aluminium Track Roller Movable Partition Walls Multi Color

Sliding Aluminium Track Roller Operable Wall Panel Hotel Movable Wall Partition System

Description:


The movable partition wall is a set of soundproof walls composed of every single partition. Each piece is equipped with two horizontal hanging wheels. It depends on the horizontal hanging wheel to make the hanging travel along the track. It can make a 90 degree right angle turn and travel freely.


Feature:


Panel faces are suspended from a steel frame with just 2 points of contact. The edges of panel faces are slotted into aluminium profiles.

This method of cladding the steel frame allows the panel faces to be acoustically separated from each other and thereby minimize the transfer of sound waves through the system.

Each panel has an extruded aluminium male profile to one vertical edge and a female profile to the other.These profiles are fitted with magnetic membranes which ensure positive interlocking of the panels.

Once the wall panels have been adjusted for height and level the roller stems are locked with a fail-safe mechanism to ensure that the panels will align perfectly every time the wall is set up.

Pressure seals extend from the top and bottom of each panel exerting a closing pressure of 2kn providing panel stability and excellent acoustic sealing.


Technical information:

Advantage:

Movable wall partition is a kind of facility with very good sound insulation, because the number can indicate how good its sound insulation is, that is, its sound insulation coefficient can reach 53 dB. Not only that, but it also has very good environmental effects. We are now paying attention to environmental protection. Our environment needs everyone to protect it. Therefore, most people will choose and trust environmentally friendly products because they are not environmentally friendly. This is also very good for our body.

Acoustic performance:

Our Top Hung acoustic operable walls were designed specifically with the office refurbishment sector in mind. With sound attentions available from 37dB RW to 53 dB RW, there is no acoustic issue between rooms that the Top Hung Operable Wall cannot cater for.

Sound reduction dB ratings are often quoted from laboratory test results which are misleading in respect of final performance values. They are merely useful for initial specification purposes. Independent on-site tests as carried out by partners are recommended as in-situ results will differ from laboratory test certification and are therefore the only true guide to achievable sound attenuation.

Our service:

Supply you excellent design proposal.

Supply you prompt and competitive price.

Supply you strict quality-compliance and punctual delivery.

Organize the shipment for you.

Reliable after service: timely service and efficient response.
