School Classroom Folding Operable Soundproof Movable Sliding Partition Walls

Name: School Classroom Folding Operable Soundproof Movable Sliding Partition Walls
Brand: EBUNGE

Explore School Classroom Folding Operable Soundproof Movable Sliding Partition Walls for overseas B2B partition projects. Share the application, opening dimensions, quantity and preferred finish with EBUNGE for project review.

Request A Quote

Product Description

Operable sliding partition walls details:

Our operable sliding partition wall Singapore is a movable soundproof room partition system which forms a removable wall. The operable sliding partition walls Singapore are often used to temporarily divide a big room into several small rooms. Unlike other room partition materials, our operable sliding partition walls has excellent soundproofing performance and they are hanging on an overhead track system.

Technical Specification Panel Configuration

The operable sliding partition walls panels are customized to meet specific requirements. Each operable sliding partition walls board thickness is 65 mm and max width is 1200 mm. Each single operable sliding partition walls panel is welded with a welded aluminum frame and 9mm MDF is mounted on both sides of the outer surface. The internal structure is made of steel mechanism, which combines excellent performance at the top and bottom of the telescopic sound seal. Internal space is filled with less than 64 kg/m3 glass wool.

Specific aluminum alloy rails to meet the necessary stacking requirements. The intersection design should prevent the track wheel from falling into the track groove. Heavy-duty multi-way roller enables easy movement of the sliding partitions for rooms through the ceiling track.The panel of operable sliding partition walls has a unique fast seal winding mechanism and a solid vertical seal edge profile to ensure that all panels fit perfectly.

Technical Information

Model	65 sliding partition walls for hotel	85 sliding partition walls for hotel	100 sliding partition walls for hotel	Ultrahigh sliding partition walls for hotel
Panel Thickness	65 MM	85 MM	100mm	100mm
Panel Width	680mm-1210mm	680mm-1230mm	680mm-1230mm	680mm-1230mm
Panel Height	2000mm-4500mm	3000mm-6500mm	5000mm-8500mm	7000mm-17000mm
Frame	6063 T6 Aluminium	6063 T6 Aluminium	6063 T6 Aluminium	6063 T6 Aluminium
Acoustic alreduction coefficient(db)	32db	45db	60db	60db
Hermetic flex distance(mm)	45mm	45mm	45mm	60mm
Weight(kg/m)	17,19,20,24	24,25,28,38	40,45,48,55	60,60,60,60
Faceplate Material	Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass	Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass	Class-fibr board, Melamine decorative lamminate board ,Gypsum board, Color steel plate, Fiberboard, Tempered glass	Class-fibr board, Melamine decorative lamminate board, Gypsum board,Color steel plate,Fiberboard, Tempered glass
Panel Surface Finish	Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment	Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment	Anodizing, electrophoresis, Powder coating; Wooden grain or surface treatment	Anodizing, electrophoresis, Powder coating; Wooden grain or customize surface treatment

Operable sliding partition walls application

Operable sliding partition walls Singapore has good sound absorbing effect and fireproof effect. It can be used in different occasions. It can be used in the meeting of the company. It is very effective to use the operable sliding partition walls Singapore in some densely populated restaurants. The surface of the operable sliding partition walls is very Smooth, it is very convenient to wipe when needed.

Operable sliding partition walls Singapore belongs to the products in the partition series, and is widely used in high-end places such as hotels, hotels, schools, business clubs, exhibition centers, etc. Therefore, the beauty and quality of the screens of the activities are the first choice for VIP customers, and the planning of the scheme should pay more attention to the overall situation. The overall look is more atmospheric and luxurious. We pay more attention to customer perception, fully consider customer needs, and provide you with a more perfect experience.

Specifications

Product Name	Operable Sliding Partition Walls
Application	Conference Room Partitions
Thickness	65 Mm(2 9/16 Inch)
System	Manual
Color	Accept Customized
Highlight	sliding folding partition , sound proof sliding partitions

Product Details

Place of Origin	Guangzhou, China
Brand Name	EBUNGE
Certification	ISO 9001
Model Number	65 mm operable sliding partition walls
Packaging Details	Paper carton, outside with wooden box
