Product Description
Factory Direct Sale Mobile Wall Partitions Restaurant Flexible Movable Partition Walls
Movable partition walls technical Information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 18000 mm |
| Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single door or Double door | ||
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
|
Finish Material |
Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
| Height (maximum height) | 3500mm |
| Width | 450~~1200mm |
| Thickness | 65mm |
| Left and right telescoping | 140mm |
| Stretching up and down | 45mm |
| Push and pull force | 20N |
| Orbital load | 225kg/m |
| Sound insulation coefficient | 32DB |
| Panel material | Three amine board |
Movable partition walls features
1. Large selection of standard finish treatment.
2. It can quickly and easily separate the space.
3. Retractable top and bottom seals allow easy movement.
4. Quick divide by simple pull / latch operation.
5. No floor track is needed for movable partition walls for rooms.
6. Tight vertical seal prevents sound leakage and helps align the panel during installation.
7. Movable partition walls are a modern decorative style with noise insulation, heat insulation, and fireproofing function.
Movable Partition Walls Cases
Project site: India
Model: BUNGE 85 mm movable partition walls
Width: 3*10550 mm,1*6900 mm
Height: 3760 mm
Total: 4 sets, 145 square meters
Finish: Melamine
Color: CS-3087
Specifications
| Product Name | Movable Partition Walls |
|---|---|
| Application | Banquet Hall, Art Gallery |
| Width | 600 - 1200 Mm |
| Height | 2000 - 4000 Meter |
| Weight | 30 Kg/sq |
| Feature | Sound Proofing |
| Highlight | acoustic folding partition , folding room partitions |
Product Details
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | BUNGE |
| Certification | ASTM E90 |
| Model Number | 85 mm movable partition walls |
| Packaging Details | Paper carton,outside with wooden boxes. |
