Product Description
Soundproof Dividers Top Hanging System Office Sliding Folding Wall Partition
Specification:
Folding partition walls are specified where functional space delineation is an integral element within the partition project. Due to their flexibility and cost effectiveness they allow large rooms to be conveniently sub-divided to maximize space insulation. Principle applications include office interiors, meeting rooms, sports and leisure facilities, schools, colleges, churches, conference and function suites, exhibition centuries, banks and restaurants.
Feature:
Individual panels help to make most of the space
Comes with top and bottom seals for easy movement.
Boasts sturdy contraction with aluminum frame.
Brags high durability for long life.
Helps to live a noise free life.
Available with different styles and designs to meet individual needs in a perfect manner.
Advantage:
We have the logistical expertise to work locally and internationally.
Assistance in choosing the best configuration for your space.
Structural preparation of the site.
Complete design and a Acoustical planning.
Maintenance free systems.
Anticipate and eliminate impact areas before they cause damage.
Soundproof partition wall surface:
Wooden (MDF, Plywood bare raw finish)(Melamine, Veneer).
Fabric (fabric with mdf board hard covers)(fabric with sponge soft covers).
Leather (leather with mdf hard covers)(leather with sponge soft covers).
Wallpaper, Vinyl, Fireproof board.
Technical information:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Our service:
Supply you excellent design proposal.
Supply you prompt and competitive price.
Supply you strict quality-compliance and punctual delivery.
Organize the shipment for you.
Reliable after service: timely service and efficient response.
Specifications
| Height | Less Than 4 M |
|---|---|
| Thickness | 65 Mm |
| Material | Mdf Board,plywood |
| Application | Hotel,restaurant |
| Service | OEM Service |
| Finished | Fabric,leather,laminate |
| Product Name | Sound Proof Partition |
| Color | Multi Color |
| Highlight | acoustic folding partition , folding room partitions |
Product Details
| Place of Origin | China,Guangzhou |
|---|---|
| Brand Name | BUNGE |
| Certification | ISO9001 |
| Model Number | Series 65 mm folding partition walls |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
