Product Description
Acoustic room dividers aluminum partition door with grill glass design for hotel
Description:
The BUNGE operable partition walls is a top quality moveable wall system that allows you to optimize the use of available space with speed and ease.
These sophisticated acoustic operable walls do not require a floor track and yet once positioned the interlocking panels form a rigid structure giving all the properties and appearance of a permanent wall.
The BUNGE movable wall system comprises panels up to 1200mm wide. Actual panel widths are determined by the site aperture, there are no standard sized panels or ‘make up’ panels
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Product Information
- Panel Suspension: Top hunge system without the need for a floor track.
- Panel Width: Each panel 600mm-1200mm.
- Track: Aluminum OR Steel Track
- Roller on panel: Single or double roller.
- Panel Frames: Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
- Top&bottm seals: Top and bottom pressure retractable seals ensure effortless moved and locked.
- Panel stacking: Numerous panel stacking options for complete flexibility.
- Panel face: MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
| sample availability subject to confirmation in 10 Days Inquiry now and you will have your sample in 10 day if you pay the express. | 3-year Warranty The acoustic room divider made of 6063-T5 alumina, anti-aging, no fading and abrasion in 10 years | OEM Service Your logo can be printed on the packaging carton |
Specifications
| Product Name | Movable Partition Wall |
|---|---|
| Material | Aluminium Frame And Mdf Board |
| Height | Less Then 4 M |
| Width | 500-1200 Mm |
| Thickness | 65mm |
| Function | Space Divide,sound Proof |
| Application | Gallery,theater,office,banquet Hall,hotel Ect |
| Highlight | sliding folding partition , sound proof sliding partitions |
Product Details
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | BUNGE |
| Model Number | Series 65 mm movable partitions |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
