Product Description
Movable Design Office Soundproof Operable Partitions Wall For Convention Center
The BUNGE movable wall is a rapid action top hung acoustic movable wall system designed for ease, efficiency and reliable daily use. Comprising of interlocking individual panels which, connected together, form a complete secure partition wall. Retractable top and bottom seals are utilised to lock each panel into place to ensure optimum acoustic performance.
Main features:
Ease of Operation
Durability
High acoustic performance up to 30-55db Rw
Acoustically tested pass doors
Nominally 65,85,100mm thick.
Comprehensive selection of finishes – inc veneer, laminate etc
Fully bespoke finishes available on request
Flexible division with various stacking options
Top hung with no floor tracks
Fire rated options available
Panels can be manufactured up to 17000 mm high
| Modernized Soundproof Movable partition | |
| 1.Hanging on ceiling | The floor without a track, just put the rail mounted on the ceiling |
| 2.Excellent Quality | Each pieces of partition can turn around 360 degree. |
| 3.Stable and secure | After partition is stable and reliable, and is not easy to swing |
| 4.Energy efficient | The large space divided into a small space, in order to reduce air conditioning power consumption; |
| 5.Heatproof&fireproof | Good heat insulation performance, Adopt effective fire prevention materials |
| 6.Elegant appearance | Surface any adornment, can unite with indoor adornment effect |
| 7.Easy to collect | Can be hidden in the special coffer, does not affect the overall appearance |
| 8.Various applications | Hotels, exhibition halls, restaurants, multi-functional rooms etc. |
Type 65
Product information: partition thickness is 65 ã, single wheel and single piece of double wheel, can open U and L door in the door, every piece of maximum load of 225 ã, screen or 22.5 ã scale range.
Product property: magnetic strip is vertically embedded, sealed and soundproof.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 32 db, density of 24 ã / ã¡.
Application: the partition height is 2.5m ~ 4m.Between 5 meters.
Type 85
Product information: partition thickness is 85 ã, single wheel and single piece of double wheel, can open U and L door in the door, every piece of screen maximum load of 450 kg, bottom top 22.5 ã scale range.
Property: magnetic strip is installed at the connection of two screens, which will attract itself when close to each other. It has good sealing and sound insulation performance.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 40 db, density of 28 ã / ã¡, .
Application: the partition height is between 3 meters and 7.5 meters.
Type 100
Product information: partition thickness is 100 ã, monolithic single wheel and single piece of type, can open U and L door in the door, every piece of screen of maximum load of 675 ã, or 30 ã scale range.
Property: magnetic strip is installed at the connection of two screens, which will attract itself when close to each other. It has good sealing and sound insulation performance.
Among them: the datum is fiber board or plywood, its sound insulation factor RW = 50 db, density of 32 ã / ã¡.
Application: suitable for partition height between 5 m ~9 m.
Specifications
| Product Name | Movable Partition Wall |
|---|---|
| Surface | MDF,Melamine |
| Thickness | 85 Mm |
| Application | Banquet Hall,hotel |
| Drawing | Free |
| Material | Wooden |
| Highlight | movable partitions systems , acoustic movable walls |
Product Details
| Place of Origin | China |
|---|---|
| Brand Name | Bunge |
| Model Number | 85 mm Movable Partition |
| Packaging Details | Carton package , Paper package |
