Movable Aluminum High Modern Wood Panels Office Hotel Sliding Folding Partition Walls

Bunge movable partition walls is made of high quality anodized aluminum frame with environmentally composite materials . The panels move on a ceiling track with no requirement of floor guides or rails , and they have a standard thickness of 65mm , 80mm and 100mm , and a width up to 1230mm . Maximum height can reach 13meter tall.

The accordion wall panel consists of a series of concave / convex profile interlocking flat panels and the fast set retractable top and bottom seals , it provides excellent acoustic insulation property of from STC – 32 to 53 in laboratory setting. Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant , schools , office , religion , hospitals , shopping arcades and many other indoor applications product.

Bunge has adopted the advance partition technology of USA , Germany and Denmark . We have professional staff with more than 10 years of experience in design , production and installation.

Features:

• Top hung system without the need for a floor track
• Retractable top and bottom seals ensure effortless movement of panels
• Combines elegance with robust construction
• Concealed or exposed panel edge profiles
• Numerous panel stacking options for complete flexibility
• Sealed for life roller assemblies provide smooth and silent movement
• The system offers various levels of sound reduction
• Extensive range of surface finishes available

Suitable used in :

1 . studios , recording rooms , listening rooms , rehearsal rooms and more professinally interspace timbre projects .

2 . theaters , indoor gymnasiums , discos , KTV rooms and more performance and entertainment location .

3 . meeting rooms , offices , halls , hotels and more sound absorption and secrecy projects .

4 . air-port , railways , bus-stops , manufactories , workshops and more noise reduction projects .

The section configuration of special wooden acoustic panel: substrate, felt and surface.

1) Substrate ( basal material ) : based on high quality of 12 / 15 / 18 mm MDF with density of 750kg / m3 ,

more choices for basal material : HDF, E1 ECO-friendly MDF and Fireproof MDF ( B1 grade ) .

2) Feld : acoustic fleece , pasted on the back of the panel , noise reducible and fire resistant ( made in CHINA , GERMANY AND FRANCE )

3) Surface : available in three different finishes : real wood veneer , printed wood melamine finished and fireproofing surface .

Technical Details
