Product Description
2017 New Design Modern Decorative Solid Wooden Folding Screen Partition Walls
Specification:
1) Easy element adjustment after installation.
2) Track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
3) Surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.
4) Consists of required full wall elements and telescopic elements with 2-point suspension system with steel-roller, extruded aluminium track.
Application:
1 studios, recording rooms, listening rooms, rehearsal rooms and more professinally interspace timbre projects.
2 theaters, indoor gymnasiums, discos, KTV rooms and more performance and entertainment location.
3 meeting rooms, offices, halls, hotels and more sound absorption and secrecy projects.
4 air-port, railways, bus-stops, manufactories, workshops and more noise reduction projects.
| Series | BG65 | BG80 / BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28–36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
We Offer:
We ensure the Quick delivery and good quality guarantee.
Our company manufacture products according to buyer’s dimension quantity, drawing or other related requirements.
After sales service including:Overseas service availabe,high quality guarantee,Free adjustment,Free training to operation and maintenance workers
.
About the products:
The movable partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.Its high performance per dollar value and the easiest in-field operation makes it very suitable for restaurant,schools,office,religion,hospitals,shopping arcades and many other indoor applications product.
Specifications
| Panel Width | 500 Mm--1220 Mm (Accept Customized) |
|---|---|
| Material | MDF+Aluminum |
| Application | Hotel,office ,conferance Room |
| Color | Color Selective (Customized) |
| Thickness | 85 Mm(3 1/4 Inch) |
| Finishing | Melanimine,fabric,leather Etc. |
| Feature | Voice Insulation |
| STC Conffcient | 32/50db |
| Highlight | acoustic operable partitions , movable acoustic partition walls |
Product Details
| Place of Origin | Guangdong |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO9001 |
| Model Number | Series 85 mm wooden partition walls |
| Packaging Details | Carton package, MDF batten on four section sides , foam board on both front face. |
