Product Description
Modern Acoustic Movable MDF Wood Folding Partition Wall For Restaurant Room
Wood Folding Partition Details
1) Wood folding partition wall interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.
2) Wood folding partition wall to ensure additional friction connection, shall be integrated with magnetic strip.
3) Wood folding movable partition wall is easy element adjustment after installation.
4) Wood folding partition wall track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.
Technical Information
|
Surface Material
|
W.G
(kg/sq.m)
|
Soundproof Factor(db)
|
Partition Frame
|
Upper & Bottom Stretching Range(mm)
|
Thk
(mm)
|
Partition Load-bearing(KG)
|
|
MDF Board
(no melamine paper)
|
28
|
38
|
Aluminum Alloy
|
15-25
|
80
|
450
|
|
Plywood Board
|
28
|
|||||
|
MDF Board
|
28
|
|||||
|
Fireproof Board
|
32
|
40
|
||||
|
Leather/Fabric Hard Cushion
|
32
|
|||||
|
Mgo Boar
|
42
|
42
|
||||
|
Steel Board
|
42
|
44
|
||||
|
Leather/Fabric Hard Cushion
(cover the edge)
|
44
|
44
|
110
|
|||
|
Leather/Fabric Soft Cushion
(cover the edge)
|
44
|
44
|
110
|
|||
|
Remarks:
|
Suggesting Height is less than 5.5m, be suitable for star class multi-function halls, Large conference centers, high class restaurants, banquet halls and so on.
|
|||||
Wood Folding Partitions Features
1. Without ground track.
2. Stable and safe.
3. Sound insulation.
4. Energy-saving insulation.
5. High-effcient fire prevetion.
6. Elegant appearance.
7. Retractable and flexible.
8. Easy storage.
9. Wide spread use.
Specifications
| Product Name | Wood Folding Partition |
|---|---|
| Based Board Material | MDF |
| Height | Max 6 Meters |
| Feature | Acoustic Partition Wall |
| Application | Restaurant Partition Wall |
| Style | Modern |
| Highlight | MDF Wood Folding Partition Walls , 6 Meters Height Folding Partition Walls , ISO 9001 Acoustic Partition Wall |
Product Details
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO 9001 |
| Model Number | Model 85 wood folding partitions |
| Packaging Details | Paper carton, outside with wooden box |
