Product Description
Kenya movable wall partition melamine MDF finish banquet wall partitions with acoustic
Description:
Equipped with our signature Acousti-Seal technology, EBUNGE’s operable partitions represent one of the most flexible solutions to making the most of your interior space. With our operable partitions, room sizes can be changed in a matter of moments to control sound and capitalize on the most efficient use of floor space.
Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Paired Panel
For straight-line openings that do not require multiple locations or offset storage, an Acoustic-Seal paired.
Single Panel
For the largest openings, storage in remote pockets, and complex partition layouts, the Acousti-Seal.
Designer Line
Let your imagination run wild. Acoustic-Seal Designer Line offers a unique platform for artistic partition.
With backing from the global leader in premium access solutions, today EBUNGE continues to guide the industry. Whether the client is a convention center covering several city blocks; a growing business that needs to add office productivity without adding real estate; or an elementary school seeking to bring new potential to their learning environment – whatever they need, EBUNGE is the name customers count on to fill spaces with possibilities.
Specifications
| Product Name | Acoustic Partition Wall |
|---|---|
| Material | Aluminium And Mdf Board |
| Height | Less Then 4 M |
| Width | 500-1200 Mm |
| Thickness | 65mm Aluminum Frame |
| Function | Banqute Hall Space Dividing |
| Finish | Melamine, Fabric, Leather, MDF Bare Finish |
| Highlight | MDF Movable Partition Walls , 4m Movable Partition Walls , 50dB Acoustic Partition Wall |
Product Details
| Place of Origin | Guangzhou,China |
|---|---|
| Brand Name | EBUNGE |
| Model Number | Series 65 mm folding partition walls |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
