Product Description
Folding Sliding Operable Partition Walls Acoustic Conference Hotel Soundproof Partition Wall Projectââ
1.Partition wall description:
| Series | BG 65 | BG 85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 4000 mm | 6000 mm | 8000 mm |
| Panel width | 600-1230 mm | 600-1230 mm | 600-1230 mm |
| Face material | 9 mm | 9 mm | 12 mm |
| Pass doors | Single Door or Double Door | ||
| Sound insulation | 20 – 32 DB | 28 – 36 DB | 40 – 50 DB |
| Finish Material | Plywood / MDF /Laminate / Melamine / Gypsum | ||
| Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized) | |||
2.Advantages of moving walls
1. EBUNGE movable walls are a hugely popular solution for spaces that need to be quickly subdivided or opened up according to the user’s changing needs. With three different ranges available in a multitude of finishes, creating the ideal system for your space is simple.
2. Our outstanding range of acoustic movable partitioning walls offers superb sound reduction properties and effortless maneuverability. The lightweight sliding panels have been expertly designed to allow users to quickly and effectively optimize space by stacking neatly at the side of a room to open it up or alternatively sliding along a top track to create multiple separate areas.
3.Installation site of the partition wall
1: Track Installation
The track is the base, is the priority among priorities of all links, through percussion drilling expansion screws, welding Angle iron and other steel materials fixed up.
2: Panel Insert
The moving door panels are suspended in the rails without any support on the ground.
3: Installation & Debugging
Free and flexible, move the door panels according to whatever you need to change the layout
4: Parking
Convenient collection, save space
Specifications
| General Use | Commercial Furniture,soundproof Partition Walls Are Used For Interior Decoration |
|---|---|
| Type | 85 Type,folding Partition |
| Material | Aluminium,Stainless Steel |
| Size | Customized,Partition Wall Customized |
| Thickness | 65mm,65~125mm |
| Application | Commercial Building And Residential House |
| Highlight | 65mm Operable Partition Walls , 125mm Operable Partition Walls |
Product Details
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO 9001 |
| Model Number | 85 mm folding partition walls |
| Packaging Details | Paper carton, outside with wooden box. |
