Product Description
85mm thickness aluminum frame soundproof operable movable partition wall for restaurant
Product Description
1.Top hung supported
2.Wide range of surface finishes
3.Individual panels that can be stored away for maximum space usage
4.Robust aluminum frame construction for demanding environments
5.Hinged pair panels for quick operation
6.Operable top and bottom seals for effortless operation
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | ||
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm | ||
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point | ||
| Frame construction | Aluminum frame | ||
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Features:
1. Without ground track: No need ground track, keep floor intact, Only need top hanger system.
2. Stable and safe: After with upper and lower telescopic pressure device, make the partition stable and secure and not easy to swing.
3. Sound insulation: the soundproof is good performance, the best sound insulation rate can reach 32/38/45db.
4. Energy-saving insulation: excellent thermal insulation properties, according to the different attendance rate, the large is divided into a small space to reduce air conditioning power consumption.
5. High-efficient fire prevention: Use highly efficient fireproof material, good fireproof performance.
About us:
1. Profession–We have professional sales staff. Any questions will be replied within 24 hours.
2. Price–Because we are factory , so we can provide higher quality and lower price products.
3 . Service–Easy and convenient to transport, we promise timely delivery date, and good after-sale service.
4. Team–We have our own engineering department, according to your request for your tailor-made for your product.
The activity partition is made up of four main parts, they are:
The main body. This part is usually the combination of high quality of wood material and aluminum alloy material.
The pulley. It is the important part of activity partition which promising the partition moves freely.
The track. This part is made for providing the railway for the movement of the pulley, without it, the free movement of this product can’t be realized.
The operating crank handle. You can use it to adjust the height as you love.
Specifications
| General Use | Soundproof Partition Walls Are Used For Interior Decoration |
|---|---|
| Material | MDF |
| Color | Customized |
| Thickness | 85mm |
| Height | Max 6 Meter |
| Width | 500-1228mm |
| Feature | Space Saving,soundproof |
| Advantage | Free Of Floor Track |
| Finishing Option | Melamine |
| Service | OEM/ODM |
| Highlight | soundproof folding partition , folding room partitions |
Product Details
| Place of Origin | China (mainland) |
|---|---|
| Brand Name | BUNGE |
| Model Number | 85mm movable partition wall |
| Packaging Details | Carton package, MDF batten on four section sides, foam board on both front face. |
