Product Description

Exhibition Hall Movable Folding Partitions Acoustic Operable Partition Walls

Acoustic Partition Walls Details


Most conference rooms,banquet halls and some exhiition hall require folding acoustic partition walls. Our standard folding acoustic partition walls work well in almost any project.



However, each project is unique and requires personalized attention to design, product selection and service. From traditional school rooms or church auditoriums to luxurious hotel banquet rooms – from basic sight separation and sound reduction to the highest quality acoustic separation – We have a solution for your design and functional requirements.



Adding standard or custom options and attachments can enhance your demountable partitioning systems. These options and accessories provide solutions that improve the safety, functionality and safety of facilities and increase their aesthetic appeal.



In addition to the applications mentioned above, these acoustic partitions are also used in hotels, shops, exhibition centers, multi-function rooms, colleges, clubs, restaurants, art centers, universities, sports centers, offices, the court, bowling centers, schools, golf clubs, and so on.

Exhibition Hall Movable Folding Partitions / Acoustic Operable Partition Walls 0

Specifications of Acoustic Movable Partition Walls System



Series BG65 BG85 BG100
Panel suspension Top hung only Top hung only Top hung only
Panel thickness 65mm 85mm 100mm
Max height 4000mm 6000mm 18000mm
Panel width 500-1200 mm 500-1200 mm 500-1200 mm
Face material 9mm 9mm 12 mm
Pass doors Single door or Double door
Sound insulation 20-32dB Rw 28-36dB Rw 32-50dB Rw
Finish Material Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized)

Exhibition Hall Movable Folding Partitions / Acoustic Operable Partition Walls 1



Advantages of Acoustic Partition Walls



Individual panels that can be stored away for maximum space usage.

Operable top and bottom seals for effortless operation.

Aluminum frame construction for enhanced acoustics.

The system offers various levels of sound reduction.

Unique track and carrier system ensuring quiet and easy operation.

Numerous panel stacking options for complete flexibility.

Top hung and no floor track.

Extensive range of surface finishes can be availabled.

Exhibition Hall Movable Folding Partitions / Acoustic Operable Partition Walls 2

Specifications

Open StyleSliding
Product NameAcoustic Partition Walls
FeatureSound Proofing
Size85 Mm
ColorAccept Customized
ApplicationBanquet Hall,office,function Room
Panel Width500 Mm--1230 Mm
Door MaterialMelamine Board
SurfaceMelamine,leather,fabric,plywood
PositionInterior
Width85 Mm(3 1/4 Inch)
Highlightacoustic operable partitions , movable acoustic partition walls

Product Details

Place of OriginGuangdong
Brand NameBANGE
CertificationISO9001
Model Number85 mm acoustic partition walls
Packaging DetailsCarton package, MDF batten on four section sides , foam board on both front face.
