Product Description
Decorative Movable Partition Exhibition Wall Sound Proof partition Show Room partition
1.Technical parameters:
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodized with sealing profiles | Aluminum anodized with sealing profiles | Aluminum anodized with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in a panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wallpaper, Vinyl, Painting, etc. (Customized) | ||
2.Acoustic performance:
Our Top Hung acoustic operable walls were designed specifically with the office refurbishment sector in mind. With sound attentions available from 37dB RW to 53 dB RW, there is no acoustic issue between rooms that the Top Hung Operable Wall cannot cater for.
Specifications
| General Use | Commercial Furniture,soundproof Partition Walls Are Used For Interior Decoration |
|---|---|
| Material | MDF,Aluminium |
| Color | Customized |
| Size | Customized,Partition Wall Customized |
| Thickness | 65~125mm |
| Application | Commercial Building And Residential House |
| Style | Modern |
| Height | HW=3500mm~16000mm |
| Feature | Conference Room Divider,Water-proof&air-proof&sound Isolation&heat Isolation,soundproof |
| Advantage | Free Of Floor Track,Professional Design Team&factory Manufacture&fashionable Outlook,Soundproof,Competitive,Fireproof |
| Finishing Option | Melamine |
| Frame Material | Aluminium,6063-T6 Aluminum Alloy |
| Highlight | MDF Sound Proof Partition , 125mm Sound Proof Partition |
Product Details
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO 9001 |
| Model Number | 65 mm sliding partition walls |
| Packaging Details | Paper carton, outside with wooden box. |
