Product Description
Banquet Hall Acoustic Movable Wooden Collapsible Partition Walls With Double Pass Door
| Modernized Soundproof Movable partition | |
| 1.Hanging on ceiling | The floor without a track, just put the rail mounted on the ceiling |
| 2.Excellent Quality | Each pieces of partition can turn around 360 degree. |
| 3.Stable and secure | After partition is stable and reliable, and is not easy to swing |
| 4.Energy efficient | The large space divided into a small space, in order to reduce air conditioning power consumption; |
| 5.Heatproof&fireproof | Good heat insulation performance, Adopt effective fire prevention materials |
| 6.Elegant appearance | Surface any adornment, can unite with indoor adornment effect |
| 7.Easy to collect | Can be hidden in the special coffer, does not affect the overall appearance |
| 8.Various applications | Hotels, exhibition halls, restaurants, multi-functional rooms etc. |
Partition detail analysis
1: Anti-skid groove is added in the single-wheel track, so that the lifting wheel can still slide smoothly under the condition of side deviation
2: Double wheel bearing 300KG
3: Rail multi-angle bevel cutting surface, no cracking using German imports inch industrial grade aluminum cutting machine cutting.45 90 180 bevel section, seamless joint using low-frequency modulation pulse MIG welding technology, no cracking.
4: Imported bearing, high speed, stable and smooth
Installation site of partition wall
1: Installation track
Track is the base, is the priority among priorities of all links, through percussion drilling expansion screws, welding Angle iron and other steel materials fixed up.
2: Insert the door panel
The moving door panels are suspended in the rails without any support on the ground.
3: Installation and debugging
Free and flexible, move the door panels according to whatever you need to change the layout
4: Close against the wall
Convenient collection, save space
Finish
We can supply any surface material according to customer’s requirement, including melamine board, decorative panel, MDF (density board) plywood, wallpaper, fabric, leather, fireproof board and decorative paint, etc
Our services
Professional drawing design
Professional production and installation team
High quality materials and accessories
It offers a three-year warranty
Mobile partition has the following characteristics
A. Sound insulation: each wallboard is fixed with A rocker and can be retractable up and down. The edge of the partition board is equipped with special sound insulation cover rubber.The concave and convex coordination between wallboard and wallboard ensures the coherence of each wallboard after it is expanded, effectively prevents the transmission of sound waves, and achieves the effect of sound insulation and heat insulation.
B. Multi-orientation: the hoisting system adopts universal pulley (steel type, nylon mute type), which can facilitate the delivery of each piece of wallboard to any position, and provide the design scheme of track direction and storage space according to customer requirements.
C. Stability: internal steel structure, aluminum frame, with telescopic system, ensuring durability and stability.
D. Integrity: no track is set on the ground, which ensures the integrity of the decorative style.
Specifications
| Product Name | Banquet Hall Partitions Wall |
|---|---|
| Material | Aluminum Frame |
| Finish | Melamine |
| Style | Morden |
| Color | Customized |
| Application | Banquet Hall |
| Advantage | Soundproof |
| Usage | Divider Room |
| Thickness | 85 Mm |
| Height | Max 6000 Mm |
| Width | 1200 Mm |
| Highlight | soundproof folding partition , folding room partitions |
Product Details
| Place of Origin | Guangdong,China |
|---|---|
| Brand Name | BUNGE |
| Model Number | 85 Series |
| Packaging Details | Partition board paper packaging, and finally packed in wooden carton |
