Product Description
Soundproof Movable Partitions Aluminum Frame Conference Room Sliding Partition Walls
Details of Sliding Partition Walls Project
This sliding partition walls project is located in San Francisco,American.EBUNGE Factory susscessfully helped our American client to divide a big meeting rooms into 2 parts.Our client chose the 85 mm thickness melamine surface panels.
There are 2 sets of sliding partition walls,the width is 25’05’’,the height is 10’.From the ceiling to the concrete floor is also 10’,actually this size was enough for us to hang and install the movable partition walls.Also we provided the angel irons for our clients.
Actually the standard height of the sliding partition walls panels can be 2.4 meters,but this project was over 3 meters.So we had divided the sliding partitions into 2 parts.Also our client chose 2 kinds of colors chart for the up and bottom parts.
EBUNGE Sliding Partition Walls FAQ
Do you provide installation?
Yes.Besides of the installation drawing and videos,there are 18+ engineers available to install the partitions all over the world,which can ensure you can install the partition walls smoothly.
Have any standard sizes and specifications for sliding partition walls?
No,all of our movable partition walls systems can be customized based on the different demands of different clients.
What about the production and delivery time?
The production time can be short,only 7-10 days are ok for us.
The delivery time for a sample is only 5-7 days,and 20-35 days by sea based on the different places.
Are you a manufacturer or a trading company?
Of course we are the 100ï¼ real manufacturer for the partition walls,we have our own showroom and factory,which located in Guangzhou,China.Very welcome to visit us.And we ensure that we can provide you a direct Factory Price.
Can I have a sample order for sliding partition walls?
How to finalize the order?
Please send us drawing about your project,tell us the size,the surfaces you need,we will provide you a unique planning for the partition walls.And after confirming all of the details,we will start production.
How many years warranty you can provide?
Technical Information:
| Series | BG65 | BG80 / BG85 | BG100 & BG125 |
| Panel suspension | Top hung only | Top hung only | Top hung only |
| Track system | Single or twin point | Single or twin point | Single or twin point |
| Panel thickness | 65mm | 80mm / 85mm | 100mm |
| Panel height | Up to 4000mm | Up to 6000mm | Up to 18000mm |
| Max height | 4000mm | 6000mm | 18000mm |
| Panel width | 600-1230mm | 600-1230mm | 600-1230mm |
| Frame construction | Aluminum frame | Aluminum frame | Aluminum frame |
| Face material | 9mm | 9mm / 12mm | 12mm |
| Fire safety | Optional Class I or O | Optional Class I or O | Optional Class I or O |
| Vertical profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles | Aluminum anodised with sealing profiles |
| Retractable seals | Aluminum black with double rubber seals |
Aluminum black with double rubber seals | Aluminum black with double rubber seals |
| Operation of seals | Manual, with supplied operating handle |
Manual, with supplied operating handle | Manual, with supplied operating handle |
| Locking | Optional lock to pass doors | Optional lock to pass doors | Optional lock to pass doors |
| Pass doors | Single open in panel or double open in two panel |
Single open in panel or double open in two panel | Single open in panel or double open in two panel |
| Sound insulation | 20-32dB Rw | 28-36dB Rw | 32-50dB Rw |
| Weight | Approx 22-35kg/sq M | Approx 25-40kg/sq M | Approx30-48kg/sq M |
| Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) | ||
Benefits:
Three(3) Years Warranty For The Partition Walls Panels
Ten(10) Years Warranty For The Tracks And Wheels
Installation Engineers Available
Specifications
| Color | Accept Customized |
|---|---|
| Size | Accept Customized |
| Thickness | 85 Mm(3 1/4 Inch) |
| Type | Commercial Furniture |
| Style | Sliding |
| Product Name | Sliding Partition Walls |
| Highlight | sliding folding partition , sound proof sliding partitions |
Product Details
| Place of Origin | China |
|---|---|
| Brand Name | EBUNGE |
| Certification | ISO9001 |
| Model Number | 85 mm sliding partition walls |
| Packaging Details | Carton package, MDF batten on four section sides ,foam board on both front face. |
