Product Description
Aluminium Track Hanging Moving Sliding Banquet Hall Hotel Conference Room Partition Wall
| Series | BG 65 | BG 85 | BG100 |
| Panel supension | Top hung only | Top hung only | Top hung only |
| Panel thickness | 65 mm | 85 mm | 100 mm |
| Max height | 400 mm | 600 mm | 800 mm |
| Panel width | 600-1230 mm | 600-1230 mm | 600-1230 mm |
| Face material | 9 mm | 9 mm | 9 mm |
| Pass doors | Single Door or Double Door | ||
| Sound insulation | 20 – 32 db | 28 – 36 db | 32 – 50 db |
| Finish Material | Plywood / MDF /Laminate / Melamine / Gypsum | ||
| Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized) | |||
Features and applications
This partition has the characteristics of high sound insulation, fire prevention, movable, simple operation, etc.
At present, activity partition, fixed partition, mobile partition series products have been widely used in hotels, guesthouses, multi-functional halls, conference rooms, banquet halls, office buildings, exhibition halls, financial institutions, government offices, hospitals, factories and other occasions.
Advantages of mobile partition
1. Trackless suspension: the floor has no track, just install the track on the ceiling.
2. Stable and safe: the partition is stable and reliable, not easy to swing.
3. Sound insulation environmental protection: sound insulation effect is good, the maximum sound insulation coefficient can reach 53dB.
4. Heat insulation and energy saving: excellent heat insulation performance, divide large space into small space to reduce the power consumption of air conditioning.
5. Efficient fire prevention: made of efficient fireproof materials, with good fireproof performance.
6. Beautiful and generous: the surface can be decorated at will, and the interior decoration effect can be unified.
7 Flexible: partition freely, promote flexible, a person can complete the whole process of partition.
8. Convenient collection: when collecting the board, the partition board can be hidden in the special storage cabinet without affecting the overall appearance.
9. Wide application: it can be used in conference hall, exhibition hall, hotel, banquet hall, office and other places.
FAQ
1:What you should you do on site?
A beam (truss)should built on site for track installation.The minimum distance leaving for track installation from false ceiling to top ceiling is 180mm.
2:How to install?
We will provide the installation manual and video guiding the installation job.We can also dispatch the installation engineer supervising the installation as request.
3:What is lead time ?
The lead time is 7 days to 10days.
4:How to transport?
Sea transport is a common mode of transportation.In an emergency,can be air freight .
5:How do the goods packing?
Carton paper package ,MDF batten cover all around cotner.
6:What is procurement procedure?
Firstly, seng us the shop drawing (if the shop drawings is not available ,you can tell us the height from false ceiling to finfshed floor and width from wall to wall)
Secondly, we offer you the movable wall layout drawings for your confirmation.
Thirdly, we quote the movable wall in acordance with confirmed drawings.
Specifications
| Product Name | Partitions Wall |
|---|---|
| Type | 85 Series |
| Style | Morden |
| Application | Banquet Hall |
| Material | Aluminum Frame |
| Finish | MDF |
| Serives | OEM ODM |
| Height | Max 6000mm |
| Thickness | 85 Mm |
| Weight | 1200mm |
| Highlight | soundproof folding partition , folding room partitions |
Product Details
| Place of Origin | Guangdong,China |
|---|---|
| Brand Name | BUNGE |
| Model Number | 85 SERIES |
| Packaging Details | Partition board paper packaging, and finally packed in wooden carton |
